Secretary of the Air Force Michael W. Wynne talks to reporters at the Arnold Engineering Development Center, Arnold Air Force Base, Tenn. about testing at Arnold to certify synthetic jet fuel for use in Air Force combat aircraft.


Arnold Engineering Development Center

Secretary of the Air Force Michael W. Wynne talks to reporters at the Arnold Engineering Development Center, Arnold Air Force Base, Tenn. about testing at Arnold to certify synthetic jet fuel for use in Air Force combat aircraft.

Related Imagery
This image shows a laser curtain that was installed on a 500-ton Cincinnati Press Brake due to a recommendation by a team member. Several AEDC craft workers were involved with the installation. The press brake is used to bend steel plates up to three-quarters of an inch thick and 14-feet long. The safety concern for the apparatus is that the press uses large flywheels and once it is triggered, it can’t be easily stopped. If a person comes into close proximity to the moving parts, they could be injured. (AEDC photo)
Members of the Manufacturing Safety Leadership Council, pictured left to right: Group Manager Dave Simmons, Inside Machinist Tim Scott, Inside Machinist Bob Williams, Non-Destructive Evaluation Technician Shannon Medley, Outside Machinist Jim Hereford, Deputy Group Manager Scott Henninger, Fabrication Planner Jeff Tate, Industrial Engineer Tracy McDonald, Sheet Metal Worker Paul Gallagher, Electrician Kendall Hampton, Pipefitter Paul Mosley, Ironworker Kevin Glaser, Chairman and boilermaker Robby Brannan, Operations and Maintenance Specialist Clara Sanders, and AEDC Safety Dave Dawkins. Members not shown are Craft Supervisor Darrell Townsend and Chemical and Material Engineer Ken Delaney. (U.S. Air Force photo/Rick Goodfriend)
A load bank, previously used to test 440 volt welders, is pictured on the left. The 40-year old load bank didn’t meet regulations for operations posing a hazard to operators. Pictured on the right is the new load bank which replaces the older version. (AEDC photo)
AEDC engineer Andrew Redmon gives a presentation at an innovation meeting held March 21 at the AEDC Model and Machine Shop. He presented ways that software improvements for the AEDC National Full-Scale Aerodynamics Complex at Ames Research Center in California are making test data analysis more user-friendly and efficient. (U.S. Air Force photo/Deidre Ortiz)
Cindy Dixon, pictured right, a small business advocate at AEDC, speaks with a vendor at the 6th Annual Small Business Industry Day March 15 at Tennessee State University. Dixon represented one of more than 200 businesses to participate in the event. The industry day was organized by Roy Rossignol, chief of Small Business with the U.S. Army Corps of Engineers Nashville District, and this year’s theme was Service Disabled Veteran-Owned. (Courtesy photo)
During an innovation meeting held March 21 at the AEDC Model and Machine Shop, engineer Justin Garrard discusses a new technology that will determine the asset health of large electric motors at AEDC. (U.S. Air Force photo/Deidre Ortiz)
AEDC craftsman Michael Money works on rake hardware at the AEDC Model and Machine Shop prior to the item being shipped to the National Full-Scale Aerodynamics Complex at the Ames Research Facility, California. The rake, which was fully fabricated at the machine shop at Arnold AFB, will be used this summer in the Phase II Flow Calibration of the 40-by-80 foot test section. The goal of the Phase II Flow Calibration is to characterize the 40-by-80 test section flow quality throughout the tunnel operational envelope and report the results. (U.S. Air Force photo/Rick Goodfriend)
The rake hardware that will be used this summer in the Phase II Flow Calibration of the 40-by-80 foot test section at the AEDC National Full-Scale Aerodynamics Complex at the Ames Research Facility, California, was fabricated at the AEDC Model and Machine Shop. Fabrication of the flow characterization rake was kept “in house” due to tight tolerance requirements, the ability to have local oversight of the fabrication efforts, and to keep the flexibility to adjust design constraints on the fly, all the while maintaining schedule for a summer 2017 test entry. The rake is designed to support 27 probes distributed in an array so that flow quality measurements can be made across a representative cross section of the wind tunnel test section. The probes will measure flow static and dynamic pressure as well as flow angles and turbulence over the survey area. Additional sensors on the array will measure tunnel total temperature. The goal of the Phase II Flow Calibration is to characterize the 40-by-80 test section flow quality throughout the tunnel operational envelope and report the results. (U.S. Air Force photo/Rick Goodfriend)
Rodger Oren, PhD., PMP
This prescribed fire shown at Arnold Air Force Base is a necessary process that promotes new growth by removing dead vegetation and suppressing woody species that would eventually grow into a forest in the absence of fire. (AEDC photo)
AEDC engineers test the Towed Airborne Plume Simulator (TAPS), a missile simulator that can be towed 500 to 1000 meters behind an aircraft to test early warning sensors on military aircraft and allow for either evasive or defensive action. The TAPS system is tested at the AEDC High Speed Fan Facility prior to a flight mission. There TAPS plume is controlled to mimic the behavior of a surface-to-air missile plume. In February, the AEDC TAPS team was named the recipient of the Outstanding Scientist Team Award, one of the AEDC Science, Engineering and Technical Management Awards presented for outstanding performance in management. (U.S. Air Force photos/Jacqueline Cowan)
AEDC engineers test the Towed Airborne Plume Simulator (TAPS), a missile simulator that can be towed 500 to 1000 meters behind an aircraft to test early warning sensors on military aircraft and allow for either evasive or defensive action. The TAPS system is tested at the AEDC High Speed Fan Facility prior to a flight mission. There TAPS plume is controlled to mimic the behavior of a surface-to-air missile plume. In February, the AEDC TAPS team was named the recipient of the Outstanding Scientist Team Award, one of the AEDC Science, Engineering and Technical Management Awards presented for outstanding performance in management. (U.S. Air Force photos/Jacqueline Cowan)
