New equipment installed at AEDC’s Hypervelocity Ballistics Range G consists of a Dicam Pro camera made by the Cooke Corporation and a Quantel Laser CFR200. The new system for taking digital photos of projectiles in the range is less cumbersome and cuts back on time that was previously spent processing film. (Photo by Rick Goodfriend)


New cameras make image capture easier at AEDC ballistics range

New equipment installed at AEDC’s Hypervelocity Ballistics Range G consists of a Dicam Pro camera made by the Cooke Corporation and a Quantel Laser CFR200. The new system for taking digital photos of projectiles in the range is less cumbersome and cuts back on time that was previously spent processing film. (Photo by Rick Goodfriend)
